IR2011PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube IR2011PBF High-Side or Low-Side 1996 gate driver 50ns -40C~150C TJ 1A 1A 1W
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.8568
≥1 USD $1.8568
Inventory: 2706
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.11mm
Length 10.8966mm
Height 4.9276mm
Technical
High Side Voltage - Max (Bootstrap) 200V
Logic Voltage - VIL, VIH 0.7V 2.2V
High Side Driver YES
Current - Peak Output (Source, Sink) 1A 1A
Gate Type N-Channel MOSFET
Driven Configuration High-Side or Low-Side
Output Peak Current Limit-Nom 1A
Channel Type Independent
Interface IC Type HALF BRIDGE BASED MOSFET DRIVER
Rise / Fall Time (Typ) 35ns, 20ns
Min Output Voltage 10V
Turn-Off Delay Time 75 ns
Fall Time (Typ) 35 ns
Rise Time 50 ns
Max Output Voltage 20V
Turn On Delay Time 20 ns
Input Type Inverting
Propagation Delay 80 ns
Max Supply Current 230μA
Output Current 1A
Power Dissipation 1W
Nominal Supply Current 230μA
Power Supplies 15V
Max Output Current 1A
Output Voltage 220V
Number of Outputs 2
Base Part Number IR2011PBF
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 10V~20V
Technology CMOS
Max Power Dissipation 1W
Subcategory MOSFET Drivers
ECCN Code EAR99
Termination Through Hole
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 1996
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
