CSD97395Q4M
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerVFDFN
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
ROHS3Compliant PWM e3 Bootstrap Circuit Half Bridge Driver -40C~150C TJ 8W 2000kHz 4.5mm
PDF
/
Buying Options
Total Price: USD $1.87
Unit Price: USD $1.8656
≥1 USD $1.8656
≥10 USD $1.67728
≥100 USD $1.581888
≥500 USD $1.347896
≥1000 USD $1.265651
≥3000 USD $1.107445
Inventory: 1933
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 3.5mm
Length 4.5mm
Technical
Load Type Inductive
Fault Protection Shoot-Through, UVLO
Switching Frequency-Max 2000kHz
Voltage - Load 4.5V~24V
Control Technique PULSE WIDTH MODULATION
Output Current per Channel 25A
Input Voltage (Max) 5.5V
Input Voltage (Min) 4.5V
Output Configuration Half Bridge
Analog IC - Other Type SWITCHING REGULATOR
Interface PWM
Input Voltage-Nom 5V
Max Output Current 60A
Number of Outputs 1
Base Part Number CSD97395
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology Power MOSFET
Max Power Dissipation 8W
Additional Feature ULTRA-LOW QUIESCENT (ULQ) CURRENT MODE; ALSO REQ VIN 24V MAX
Applications Synchronous Buck Converters
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Bootstrap Circuit
JESD-609 Code e3
Series NexFET?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-PowerVFDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
