VN5770AKTR-E
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
Current Limiting ESD Over Temperature Over Voltage Short Circuit UVLO TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE Tape & Reel (TR) DUAL bridge driver 8.5A 13V 160m Ohm 2.65mm
PDF
/
Buying Options
Total Price: USD $8.3
Unit Price: USD $8.2954
≥1 USD $8.2954
≥10 USD $6.80675
≥100 USD $6.59395
≥500 USD $6.38115
≥1000 USD $6.16835
Inventory: 1459
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Height Seated (Max) 2.65mm
Technical
Load Type Inductive, Capacitive, Resistive
Output Current Flow Direction SOURCE
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Turn Off Time 250 μs
Rds On (Typ) 160m Ω
Output Peak Current Limit-Nom 12A
Turn On Time 300 μs
Fault Protection Current Limiting, ESD, Over Temperature, Over Voltage, Short Circuit, UVLO
Voltage - Load 41V Max
Output Current per Channel 8.5A
Output Configuration Half Bridge (2)
Interface Logic
Qualification Status Not Qualified
Pin Count 28
Base Part Number VN5770
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 13V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~36V
Technology Power MOSFET
HTS Code 8542.39.00.01
Applications DC Motors, General Purpose, Relays
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series OMNIFET II?, VIPower?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
