L6201PS
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.433, 11.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
Over Temperature THERMAL ACTIVE (Last Updated: 6months ago) Lead Free bridge driver 5A 48V 300m Ohm 3.3mm
PDF
/
Buying Options
Total Price: USD $8.23
Unit Price: USD $8.228
≥1 USD $8.228
≥10 USD $7.4316
≥100 USD $7.085989
≥500 USD $6.152828
≥1000 USD $5.876288
≥3000 USD $5.357783
Inventory: 1229
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.433, 11.00mm Width) Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
JESD-609 Code e3
Feature Bootstrap Circuit
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Resistance 300mOhm
Terminal Finish Matte Tin (Sn) - annealed
Applications DC Motors, General Purpose
Technology BCDMOS
Voltage - Supply 12V~48V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 36V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L6201
Pin Count 20
Output Voltage 60V
Max Output Current 5A
Operating Supply Voltage 36V
Number of Channels 2
Interface Logic
Operating Supply Current 15mA
Output Configuration Half Bridge (2)
Output Current 5A
Output Current per Channel 4A
Rise Time 300 ns
Collector Emitter Voltage (VCEO) 48V
Max Collector Current 4A
Release Time 400 ns
Voltage - Load 12V~48V
Fault Protection Over Temperature
Output Peak Current Limit-Nom 5A
Rds On (Typ) 300m Ω
Built-in Protections THERMAL
Motor Type Brushed
Load Type Inductive
Dimensions
Height 3.3mm
Length 16mm
Width 11.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
