TDA21201-S7
RoHS
/
Package TO-220-7
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
Non-RoHS Compliant SOURCE SINK PWM R-XZFM-T7 Half Bridge Driver -25C~125C TJ 4.8m Ohm LS 13.3m Ohm HS 12V 30A
PDF
/
Buying Options
Total Price: USD $22.61
Unit Price: USD $22.60525
≥1 USD $22.60525
≥10 USD $18.5478
≥100 USD $17.9683
≥500 USD $17.3888
≥1000 USD $16.8093
Inventory: 3705
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Load Type Inductive
Output Current Flow Direction SOURCE SINK
Built-in Protections OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Rds On (Typ) 4.8m Ω LS, 13.3m Ω HS
Output Peak Current Limit-Nom 30A
Fault Protection Over Temperature, Shoot-Through, UVLO
Current - Output / Channel 30A
Voltage - Load 9V~15V
Output Configuration Half Bridge
Interface PWM
Qualification Status COMMERCIAL
JESD-30 Code R-XZFM-T7
Pin Count 3
Reach Compliance Code unknown
Supply Voltage 12V
Number of Functions 1
Terminal Position ZIG-ZAG
Voltage - Supply 9V~15V
Technology Power MOSFET
Applications Synchronous Buck Converters
Terminal Finish NOT SPECIFIED
Number of Terminations 7
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Bootstrap Circuit
Packaging Tube
Operating Temperature -25°C~125°C TJ
Physical
Surface Mount NO
Package / Case TO-220-7
Mounting Type Through Hole
