RoHS
RoHS RoHS compliant
Package 29-SSIP Module, 21 Leads, Formed Leads
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description ROHS3Compliant Logic Bootstrap Circuit Obsolete Half Bridge (3) Driver -20C~150C TJ 400V Max 10A
PDF
/
Inventory: 6905
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Load Type Inductive
Current - Peak Output 20A
Fault Protection Current Limiting, UVLO
Current - Output / Channel 10A
Voltage - Load 400V Max
Output Configuration Half Bridge (3)
Interface Logic
Voltage - Supply 12.5V~17.5V
Technology IGBT
Applications AC Motors
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Bootstrap Circuit
Packaging Tube
Operating Temperature -20°C~150°C TJ

Physical

Supplier Device Package 21-SIP
Package / Case 29-SSIP Module, 21 Leads, Formed Leads
Mounting Type Through Hole
