FDMF5822DC
RoHS
RoHS compliant
RoHS compliantPackage 31-PowerWFQFN
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
ROHS3Compliant PWM e3 Bootstrap Circuit Latch Function Status Flag Half Bridge Driver -40C~125C TJ 3ns 800mum 470m Ohm LS 680m Ohm HS
PDF
/
Buying Options
Total Price: USD $3.03
Unit Price: USD $3.0272
≥1 USD $3.0272
≥10 USD $2.54496
≥100 USD $2.058496
≥500 USD $1.829784
≥1000 USD $1.566761
Inventory: 1233
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 5mm
Height 800μm
Technical
Load Type Inductive
Rds On (Typ) 470m Ω LS, 680m Ω HS
Number of Drivers 2
Fault Protection Over Temperature, UVLO
Voltage - Load 4.5V~16V
Fall Time (Typ) 3 ns
Rise Time 4ns
Output Current per Channel 55A
Max Input Voltage 5.5V
Min Input Voltage 4.5V
Output Current 55A
Output Configuration Half Bridge
Nominal Supply Current 2mA
Interface PWM
Max Output Current 55A
Number of Outputs 1
Voltage - Supply 4.5V~5.5V
Technology UMOS
Applications Synchronous Buck Converters
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Bootstrap Circuit, Latch Function, Status Flag
JESD-609 Code e3
Series PowerTrench?, SyncFET?
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Weight 205mg
Number of Pins 31
Package / Case 31-PowerWFQFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 15 Weeks
