FDMF2011
RoHS
RoHS compliant
RoHS compliantPackage 36-SMD Module
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
UVLO ACTIVE (Last Updated: 1week ago) Tape & Reel (TR) UNSPECIFIED bridge driver 20A 80V 7.3m Ohm LS 7.7m Ohm HS 0.8mm
PDF
/
Buying Options
Total Price: USD $66.09
Unit Price: USD $66.0877
≥1 USD $66.0877
≥10 USD $64.0224
≥100 USD $61.9571
≥500 USD $59.8918
≥1000 USD $53.6959
Inventory: 1186
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 7.5mm
Height Seated (Max) 0.8mm
Technical
Load Type Inductive, Capacitive
Rds On (Typ) 7.3m ?? LS, 7.7m ?? HS
Fault Protection UVLO
Current - Output / Channel 20A
Voltage - Load 3V￣80V
Switcher Configuration BUCK-BOOST
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 80V
Input Voltage (Min) 3V
Output Configuration Half Bridge
Analog IC - Other Type SWITCHING CONTROLLER
Interface PWM
Input Voltage-Nom 50V
JESD-30 Code R-XXMA-X37
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Voltage - Supply 10V￣20V
Technology Power MOSFET
Applications DC Motors, General Purpose
Terminal Finish Tin (Sn)
Number of Terminations 37
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Bootstrap Circuit
JESD-609 Code e3
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40??C￣125??C TJ
Physical
Weight 145.646mg
Package / Case 36-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
Alternative Model
