MC34931SEK
RoHS
RoHS compliant
RoHS compliantPackage 32-SSOP (0.295, 7.50mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
Current Limiting Over Temperature Short Circuit UVLO Tube DUAL DC Motors General Purpose bridge driver 5A 5V~36V 120m Ohm 0.635mm
PDF
/
Buying Options
Total Price: USD $16.11
Unit Price: USD $16.10915
≥1 USD $16.10915
≥10 USD $13.2183
≥100 USD $12.80505
≥500 USD $12.3918
≥1000 USD $11.97855
Inventory: 1115
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Load Type Inductive
Rds On (Typ) 120m Ω
Fault Protection Current Limiting, Over Temperature, Short Circuit, UVLO
Current - Output / Channel 5A
Voltage - Load 5V~36V
Output Configuration Half Bridge (2)
Analog IC - Other Type BRUSH DC MOTOR CONTROLLER
Interface Logic
Power Supplies 5/36V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G32
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.635mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V~36V
Technology Power MOSFET
Subcategory Motion Control Electronics
HTS Code 8542.39.00.01
Applications DC Motors, General Purpose
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Status Flag
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Surface Mount YES
Package / Case 32-SSOP (0.295, 7.50mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
