BTS7710GPNTMA1
RoHS
/
Package TO-263-18 (15 Leads + 3 Tabs)
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
ESD Over Temperature Short Circuit UVLO Tape & Reel (TR) SINGLE BTS7710 bridge driver 15A 12V 40m Ohm LS 70m Ohm HS 21.6mm
PDF
/
Inventory: 6567
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-18 (15 Leads + 3 Tabs)
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2001
Series TrilithIC?
Feature Status Flag
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 15
ECCN Code EAR99
Applications DC Motors, General Purpose
HTS Code 8542.39.00.01
Technology DMOS
Voltage - Supply 1.8V~42V
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 1.4mm
Base Part Number BTS7710
Pin Count 4
JESD-30 Code R-PSSO-G15
Max Output Current 15A
Supply Voltage-Max (Vsup) 42V
Supply Voltage-Min (Vsup) 3.2V
Interface Logic
Analog IC - Other Type BRUSH DC MOTOR CONTROLLER
Output Configuration Half Bridge (2)
Voltage - Load 1.8V~42V
Fault Protection ESD, Over Temperature, Short Circuit, UVLO
Rds On (Typ) 40m Ω LS, 70m Ω HS
Load Type Inductive
Dimensions
Length 21.6mm
Width 9.25mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Alternative Model
