MCP3909T-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Energy Metering
Description
MCP3909 Tape & Reel (TR) 8542.39.00.01 Matte Tin (Sn) - annealed energy meter 8.2mm 4.5V 390kOhm 2.3mA
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.316839
≥1 USD $1.316839
≥10 USD $1.136971
≥30 USD $1.024062
≥100 USD $0.908527
≥500 USD $0.857324
≥1000 USD $0.835004
Inventory: 2603
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Package / Case 24-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 24
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.39.00.01
Subcategory Other Analog ICs
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP3909
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Analog IC - Other Type ANALOG CIRCUIT
Current - Supply 2.3mA
Supply Current-Max (Isup) 2.8mA
Input Impedance 390kOhm
Meter Type Single Phase
Measurement Error 0.1%
Voltage - I/O Low 0.85V
Voltage - I/O High 2.4V
Dimensions
Height Seated (Max) 2mm
Length 8.2mm
Width 5.3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
