MAX78615+PPM/C01
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Energy Metering
Description
ROHS3Compliant NO LEAD 3Phase MICROPROCESSOR CIRCUIT IC 3 Phase Meter -40C~85C 8.1mA 3.3V 4mm
PDF
/
Inventory: 5787
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-WFQFN Exposed Pad
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2015
JESD-609 Code e3
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Terminal Finish Matte Tin (Sn)
HTS Code 8542.31.00.01
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code S-XQCC-N24
Operating Supply Current 8.1mA
uPs/uCs/Peripheral ICs Type MICROPROCESSOR CIRCUIT
Meter Type 3 Phase
Voltage - I/O Low 0.8V
Voltage - I/O High 2V
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
