CD4056BPWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
1Digit Tape & Reel (TR) CD4056 Nickel/Palladium/Gold (Ni/Pd/Au) display driver -1.9mA 18V 5mm -55C~125C
PDF
/
Inventory: 1984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 5mm
Technical
Number of Backplanes 0-BP
Digits or Characters 1 Digit
Low Level Output Current 3.6mA
High Level Output Current -1.9mA
Max Frequency 8MHz
Display Type LCD
Max Input Voltage 18V
Number of Inputs 4
Logic Function Decoder, Latch
Min Input Voltage 3V
Turn On Delay Time 1.3 μs
Quiescent Current 100μA
Propagation Delay 1.3 μs
Max Supply Current 300μA
Operating Supply Current 40nA
Interface BCD
Configuration 7 Segment
Polarity Non-Inverting
Number of Elements 1
Number of Outputs 7
Pin Count 16
Base Part Number CD4056
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Subcategory Other Interface ICs
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 61.887009mg
Number of Pins 16
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
