CD4054BNSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
LIQUID CRYSTAL DISPLAY DRIVER ROHS3Compliant Surface Mount Obsolete LCD Driver -55C~125C 10.2mm 18V 40nA
PDF
/
Inventory: 9405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209, 5.30mm Width)
Number of Pins 16
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CD4054
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 18V
Configuration 4 Segment
Operating Supply Current 40nA
Display Type LCD
Interface IC Type LIQUID CRYSTAL DISPLAY DRIVER
Number of Segments 4
Multiplexed Display Capability NO
Data Input Mode PARALLEL
Dimensions
Height Seated (Max) 2mm
Length 10.2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
