CP2403-GM
RoHS
/
Package 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
Tube CP240 64Segment SERIAL display driver 620muA 3.3V 1.05mm -40C~85C
PDF
/
Buying Options
Total Price: USD $25.85
Unit Price: USD $25.8457
≥1 USD $25.8457
≥10 USD $21.20685
≥100 USD $20.54375
≥500 USD $19.8816
≥1000 USD $19.2185
Inventory: 1960
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height 1.05mm
Technical
Data Input Mode SERIAL
Touchscreen No
Multiplexed Display Capability NO
Number of Segments 64
Display Type LCD
Max Supply Current 740μA
RAM Size 256kB
Nominal Supply Current 620μA
Operating Supply Current 620μA
Interface I2C, SMBus
Configuration 64 Segment
JESD-30 Code S-XQCC-N48
Pin Count 48
Base Part Number CP240
Frequency 25MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 1.8V~3.6V
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 50.008559mg
Number of Pins 32
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
