MAX6957ANI+
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
ROHS3Compliant Through Hole Obsolete DUAL LED Driver -40C~125C 34.795mm 3.3V 180muA
PDF
/
Inventory: 9434
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 34.795mm
Height Seated (Max) 4.572mm
Technical
Multiplexed Display Capability NO
Number of Segments 20
Display Type LED
Current - Supply 180μA
Interface 4-Wire Serial
Configuration 7, 16, 20 Segment
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case 28-DIP (0.300, 7.62mm)
Mounting Type Through Hole
