MAX6956ANI+
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
ROHS3Compliant Through Hole Obsolete DUAL LED Driver -40C~125C 34.795mm 3.3V 180muA
PDF
/
Buying Options
Total Price: USD $86.14
Unit Price: USD $86.144847
≥1 USD $86.144847
≥10 USD $81.268723
≥100 USD $76.668612
≥500 USD $72.328882
≥1000 USD $68.234788
Inventory: 6879
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 34.795mm
Height Seated (Max) 4.572mm
Technical
Display Type LED
Current - Supply 180μA
Interface I2C
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case 28-DIP (0.300, 7.62mm)
Mounting Type Through Hole
