MAX6954APL image
Favorite
MAX6954APL image
Favorite
RoHS
/
Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description Non-RoHS Compliant Through Hole Obsolete DUAL LED Driver 8MHz -40C~125C 52.075mm 3.3V
PDF
/
Inventory: 5563
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Through Hole
Package / Case 40-DIP (0.600, 15.24mm)
Surface Mount NO

Technical

Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Terminal Finish TIN LEAD
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 40
JESD-30 Code R-PDIP-T40
Qualification Status COMMERCIAL
Configuration 7, 14, 16 Segment, Common Cathode
Interface 4-Wire Serial
Current - Supply 22mA
Display Type LED
fmax-Min 8 MHz
Number of Segments 24
Multiplexed Display Capability YES
Digits or Characters 8 Digits, 16 Digits

Dimensions

Height Seated (Max) 5.08mm
Length 52.075mm
Width 15.24mm

Compliance

RoHS Status Non-RoHS Compliant
