ICM7218BIJI
RoHS
/
Package 28-CDIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
8Digits Tube ICM7218 Tin/Lead (Sn/Pb) display driver 700muA 2.5V 37.85mm -40C~85C
PDF
/
Buying Options
Total Price: USD $27.65
Unit Price: USD $27.64975
≥1 USD $27.64975
≥10 USD $22.68695
≥100 USD $21.97825
≥500 USD $21.2686
≥1000 USD $20.5599
Inventory: 1153
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 15.24mm
Length 37.85mm
Height Seated (Max) 5.92mm
Technical
Digits or Characters 8 Digits
Data Input Mode PARALLEL
Display Mode DIG; SEG
Multiplexed Display Capability YES
Number of Segments 7
Display Type LED
Current - Supply 700μA
Output Current 50mA
Interface Serial
Configuration 7 Segment
Output Voltage 2.5V
JESD-30 Code R-CDIP-T28
Pin Count 28
Base Part Number ICM7218
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4V~6V
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Published 2001
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 28-CDIP (0.600, 15.24mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
