TC7116ACPL
RoHS
RoHS compliant
RoHS compliantPackage 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
A/D 3.5Digits Tube TC7116A Matte Tin (Sn) display driver 800muA 9V 4.06mm 0C~70C
PDF
/
Buying Options
Total Price: USD $6.84
Unit Price: USD $6.8419
≥1 USD $6.8419
≥10 USD $5.6145
≥100 USD $5.43875
≥500 USD $5.263
≥1000 USD $5.0882
Inventory: 4199
Minimum: 1
-
+
Technical Details
Dimensions
Length 52.45mm
Width 14.1mm
Height 4.06mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Technical
Digits or Characters A/D 3.5 Digits
Touchscreen No
Analog Input Voltage-Min 2.4V
Number of Segments 7
Number of A/D Converters 1
Max Frequency 48kHz
Display Type LCD
Linearity Error-Max (EL) 0.05%
Power Consumption 10mW
Output Bit Code BINARY
Number of Analog In Channels 1
Resolution 0.4375 B
Converter Type ADC, DUAL-SLOPE
Number of Bits 3
Max Supply Current 1.8mA
Power Dissipation 1.23W
Nominal Supply Current 800μA
Operating Supply Current 800μA
Interface Parallel
Configuration 7 Segment
Power Supplies 9V
Polarity Unipolar
Operating Supply Voltage 9V
Pin Count 40
Base Part Number TC7116A
Terminal Pitch 2.54mm
Supply Voltage 9V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1.23W
Subcategory Analog to Digital Converters
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 40
Package / Case 40-DIP (0.600, 15.24mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
