MAX7219EWG+
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
8Digits Tube MAX7219 7Segment + DP display driver -2mA 5.5V 2.35mm -40C~85C
PDF
/
Buying Options
Total Price: USD $2.88
Unit Price: USD $2.87845
≥1 USD $2.87845
≥10 USD $2.71552
≥100 USD $2.56181
≥500 USD $2.4168
≥1000 USD $2.28
≥3000 USD $2.15094
Inventory: 3797
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.6mm
Length 15.6mm
Height 2.35mm
Technical
Digits or Characters 8 Digits
Multiplexed Display Capability YES
Switching Frequency 10MHz
Number of Segments 8
fmax-Min 1.3 MHz
Low Level Output Current 5mA
High Level Output Current -2mA
Display Type LED
Input Characteristics STANDARD
Output Polarity TRUE
Output Characteristics TOTEM-POLE
Max Input Voltage 5.5V
Min Input Voltage 4V
Max Supply Current 330mA
Output Current 320mA
Power Dissipation 941mW
Operating Supply Current 330mA
Interface 4-Wire Serial
Configuration 7 Segment + DP
Power Supplies 5V
Operating Supply Voltage 5.5V
Number of Outputs 16
Pin Count 24
Base Part Number MAX7219
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~5.5V
Technology MOS
Max Power Dissipation 941mW
Subcategory Display Drivers
Additional Feature COMMON-CATHODE
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1997
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
