MAX6950EEE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
5Digits Tube MAX6950 Matte Tin (Sn) display driver -50mA 5.5V 1.55mm -40C~85C
PDF
/
Buying Options
Total Price: USD $17.06
Unit Price: USD $17.0632
≥1 USD $17.0632
≥10 USD $15.67896
≥100 USD $15.02864
≥500 USD $13.241536
≥1000 USD $12.59163
≥3000 USD $11.779258
Inventory: 411
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 3.99mm
Length 4.98mm
Height 1.55mm
Technical
Digits or Characters 5 Digits
Multiplexed Display Capability YES
Number of Segments 40
fmax-Min 8 MHz
Low Level Output Current 400mA
High Level Output Current -50mA
Display Type LED
Max Input Voltage 5.5V
Min Input Voltage 2.7V
Max Supply Current 15mA
Power Dissipation 667mW
Operating Supply Current 10mA
Interface 3-Wire Serial
Configuration 7 Segment
Power Supplies 3/5V
Operating Supply Voltage 5.5V
Pin Count 16
Base Part Number MAX6950
Terminal Pitch 0.635mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology CMOS
Max Power Dissipation 667mW
Subcategory Display Drivers
HTS Code 8542.39.00.01
Additional Feature COMMON-CATHODE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-SSOP (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
