ICM7211IPL+
RoHS
RoHS compliant
RoHS compliantPackage 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description
ROHS3Compliant Through Hole Active DUAL LCD Driver -20C~85C 52.075mm 5V 10muA
PDF
/
Buying Options
Total Price: USD $10.93
Unit Price: USD $10.925748
≥1 USD $10.925748
≥10 USD $10.307311
≥100 USD $9.723877
≥500 USD $9.173475
≥1000 USD $8.654214
Inventory: 1171
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 15.24mm
Length 52.075mm
Height Seated (Max) 5.08mm
Technical
Digits or Characters 4 Digits
Data Input Mode PARALLEL
Multiplexed Display Capability NO
Number of Segments 7
Display Type LCD
Current - Supply 10μA
Interface BCD
Configuration 7 Segment
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T40
Pin Count 40
Base Part Number ICM7211
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 3V~6V
Technology CMOS
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2003
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Surface Mount NO
Package / Case 40-DIP (0.600, 15.24mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 6 Weeks
