TPS259823LNRGET
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
PWR MGMT PWR DISTRIBUTION
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.2648
≥1 USD $3.2648
≥10 USD $2.93216
≥100 USD $2.771648
≥500 USD $2.402136
Inventory: 334
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Accuracy ±5%
Adjustable Threshold YES
Current - Output 15A
Voltage - Input 2.7V~24V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Function Current Monitor
JESD-30 Code S-PQCC-N24
Base Part Number TPS259823
Terminal Pitch 0.5mm
Supply Voltage 5V
Terminal Form NO LEAD
Terminal Position QUAD
Additional Feature OVERVOLTAGE THRESHOLD IS 7.6V
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
