TPS259620DDAR
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerSOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
2.7-19V 130MA-2A SURGE CLAMPING
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.68992
≥100 USD $0.654368
≥500 USD $0.537592
≥1000 USD $0.502586
≥3000 USD $0.444136
Inventory: 1192
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.89mm
Height Seated (Max) 1.7mm
Technical
Accuracy ±10.4%
Adjustable Threshold YES
Current - Output 2A
Voltage - Input 2.7V~19V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 19V
Function Electronic Fuse
JESD-30 Code R-PDSO-G8
Base Part Number TPS259620
Terminal Pitch 1.27mm
Supply Voltage 12V
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 8-PowerSOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
