LM3813MX-7.0
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
IC CURRENT GAUGE PREC EVAL 8SOIC
PDF
/
Inventory: 9801
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Additional Feature SEATED HGT-NOM
HTS Code 8542.39.00.01
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 1.27mm
Base Part Number LM3813
JESD-30 Code R-PDSO-G8
Function Current Gauge
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 2V
Number of Channels 1
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Voltage - Input 2V~5.25V
Adjustable Threshold NO
Accuracy ±4%
Sensing Method Low-Side
Switching Frequency 20Hz
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
