INA301A1IDGKT
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
IC COMPARATOR SENSING AMP 8VSSOP
PDF
/
Buying Options
Total Price: USD $3.41
Unit Price: USD $3.4144
≥1 USD $3.4144
≥10 USD $3.06768
≥100 USD $2.899776
≥500 USD $2.513104
Inventory: 1172
Minimum: 1
-
+
Technical Details
Technical
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Subcategory Operational Amplifier
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number INA301
Function Current Monitor
Number of Channels 1
Voltage - Input 0V~36V
Slew Rate 4 V/us
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 110 dB
Unity Gain BW-Nom 550 kHz
Supply Voltage Limit-Max 6V
Sensing Method High/Low-Side
Common Mode Voltage-Max 36V
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height 1.07mm
Length 3mm
Width 3mm
Thickness 970μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
