INA198AIDBVRG4
RoHS
/
Package SOT-23-5
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
IC CURRENT MONITOR 3% SOT23-5
PDF
/
Buying Options
Total Price: USD $7.32
Unit Price: USD $7.316411
≥1 USD $7.316411
≥10 USD $6.902277
≥100 USD $6.511586
≥500 USD $6.143002
≥1000 USD $5.795289
Inventory: 1271
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Power Supply Rejection Ratio (PSRR) 106dB
Voltage Gain 40dB
Bandwidth 200 kHz
Input Offset Voltage (Vos) 2mV
Current - Input Bias 16μA
Common Mode Rejection Ratio 80 dB
Amplifier Type OPERATIONAL AMPLIFIER
Slew Rate 1 V/μs
Accuracy 1 %
Nominal Supply Current 900μA
Min Supply Voltage 2.7V
Max Supply Voltage 18V
Number of Channels 1
Temperature Grade AUTOMOTIVE
Number of Elements 2
Pin Count 5
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Operational Amplifier
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 2
Pbfree Code no
JESD-609 Code e4
Packaging Tape and Reel
Physical
Weight 17.491656mg
Number of Pins 5
Package / Case SOT-23-5
Mount Surface Mount
