MAX4211DEUE+
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
Current & Power Monitors & Regulators High-Side Power And Current Monitor
PDF
/
Buying Options
Total Price: USD $4.69
Unit Price: USD $4.6904
≥1 USD $4.6904
≥10 USD $4.20992
≥100 USD $3.448958
≥500 USD $3.272104
≥1000 USD $2.936067
≥3000 USD $2.476197
Inventory: 162
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Weight 172.98879mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX4211
Function Current Monitor
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 2.7V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Voltage - Input 4V~28V
Nominal Supply Current 1.1mA
Adjustable Threshold NO
Accuracy ±0.5%
Sensing Method High-Side
Dimensions
Height Seated (Max) 1.1mm
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
