MAX4211AEUE
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
IC CURRENT MONITOR 1.5% 16TSSOP
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 1610
Minimum: 1
-
+
Technical Details
Technical
Min Supply Voltage 2.7V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Voltage - Input 4V~28V
Nominal Supply Current 1.1mA
Adjustable Threshold NO
Accuracy ±0.5%
Common Mode Rejection Ratio 80 dB
Input Offset Voltage (Vos) 1.5mV
Bandwidth 220 kHz
Sensing Method High-Side
Input Bias Current 14μA
Number of Amplifiers 2
Max Supply Voltage 5.5V
Number of Channels 1
Power Supplies 3/5V
Function Current Monitor
Base Part Number MAX4211
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 5mm
Height Seated (Max) 1.1mm
