MAX4210BEUA
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
IC CURRENT MONITOR 1.5% 8MSOP
PDF
/
Buying Options
Total Price: USD $2.92
Unit Price: USD $2.917137
≥1 USD $2.917137
≥10 USD $2.752021
≥100 USD $2.596242
≥500 USD $2.449292
≥1000 USD $2.310652
Inventory: 1082
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Sensing Method High-Side
Supply Current-Max (Isup) 0.67mA
Accuracy ±0.5%
Adjustable Threshold NO
Voltage - Input 4V~28V
Operating Supply Current 380μA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Number of Channels 1
Power Supplies 3/5V
Function Current Monitor
Base Part Number MAX4210
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
