MAX20313EWC+
RoHS
RoHS compliant
RoHS compliantPackage 12-WFBGA, WLBGA
Category Integrated Circuits (ICs) / PMIC - Current Regulation/Management
Description
IC CURRENT LIMIT SWITCH ADJ 12WL
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.230683
≥1 USD $2.230683
≥10 USD $2.104419
≥100 USD $1.985306
≥500 USD $1.872924
≥1000 USD $1.766907
Inventory: 1435
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.448mm
Length 1.648mm
Height Seated (Max) 0.69mm
Technical
Nominal Input Voltage 5.5V
Accuracy ±5%
Adjustable Threshold YES
Current - Output 20mA
Voltage - Input 2.5V~5.5V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.5V
Function Current Switch
JESD-30 Code R-PBGA-B12
Base Part Number MAX20313
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Supply Voltage 4.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Technology BICMOS
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 12-WFBGA, WLBGA
Mounting Type Surface Mount
