TPS65811RTQT
RoHS
RoHS compliant
RoHS compliantPackage 56-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Contains Lead ROHS3Compliant Multi-Function Controller Discontinued IC Multi-Function Controller -40C~85C TA 8mm 18V 1.5A
PDF
/
Buying Options
Total Price: USD $10.72
Unit Price: USD $10.71505
≥1 USD $10.71505
≥10 USD $8.79225
≥100 USD $8.51675
≥500 USD $8.2422
≥1000 USD $7.96765
Inventory: 1135
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 56-VFQFN Exposed Pad
Number of Pins 56
Weight 197.908021mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 56
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Power Management Circuits
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Base Part Number TPS65811
Function Multi-Function Controller
Output Voltage 3.3V
Number of Channels 9
Interface I2C, USB
Max Supply Voltage 18V
Min Supply Voltage 3V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Output Current 1.5A
Adjustable Threshold YES
Fault Protection Over Current, Over Voltage
Battery Chemistry Lithium Ion/Polymer
Number of Cells 1
Dimensions
Length 8mm
Width 8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
