BQ771612DPJT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description ACTIVE (Last Updated: 3days ago) DUAL Tape & Reel (TR) e4 battery management 1muA 20V 3mm -40C~110C TA
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $1.25576
≥100 USD $1.192224
≥500 USD $0.979176
Inventory: 1115
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-WDFN Exposed Pad
Number of Pins 8
Weight 10.886217mg

Technical

Operating Temperature -40°C~110°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Subcategory Power Management Circuits
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number BQ771612
Function Battery Protection
Qualification Status Not Qualified
Output Voltage 6V
Max Supply Voltage 20V
Min Supply Voltage 3V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Operating Supply Current 1μA
Output Current 4.5mA
Supply Current-Max (Isup) 0.002mA
Threshold Voltage 3.9
Fault Protection Over Voltage
Battery Chemistry Lithium-Ion
Number of Cells 2 ~ 4
Number of Batteries 4

Dimensions

Height 800μm
Length 4mm
Width 3mm
Thickness 750μm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
