BQ7694002DBTR
RoHS
RoHS compliant
RoHS compliantPackage 44-TFSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free Gold ROHS3Compliant Battery Monitor IC Battery Monitor -40C~85C TA 4.4mm 25V 5mA
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 10296
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 4.4mm
Length 11mm
Height 1.2mm
Technical
Number of Cells 9 ~ 15
Battery Chemistry Multi-Chemistry
Fault Protection Over Current, Over/Under Voltage, Short Circuit
Supply Current-Max (Isup) 5mA
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Interface I2C
Number of Channels 1
Supply Voltage-Min (Vsup) 6V
Operating Supply Voltage 25V
Output Voltage 16V
Function Battery Monitor
Base Part Number BQ7694002
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8542.39.00.01
Additional Feature DETECTION THRESHOLD VOLTAGE= 0.7V
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 139.309557mg
Number of Pins 44
Package / Case 44-TFSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
