BQ29718DSET
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
ACTIVE (Last Updated: 1day ago) DUAL Tape & Reel (TR) e4 battery management 8V 1.5mm -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.056
≥1 USD $1.056
≥10 USD $0.94688
≥100 USD $0.898304
≥500 USD $0.737968
Inventory: 796
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 750μm
Width 1.5mm
Length 1.5mm
Height 800μm
Technical
Number of Cells 1
Battery Chemistry Lithium Ion/Polymer
Fault Protection Over Current, Over/Under Voltage, Short Circuit
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1.5V
Max Supply Voltage 8V
Number of Channels 1
Function Battery Protection
Base Part Number BQ29718
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.6V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 6
Surface Mount YES
Package / Case 6-WFDFN
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
