BQ296112DSGR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description ACTIVE (Last Updated: 4days ago) DUAL Tape & Reel (TR) e4 battery management 20V 2mm -40C~110C TA
PDF
/
Inventory: 9399
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 750μm
Width 2mm
Length 2mm
Height 800μm

Technical

Number of Cells 2 ~ 4
Battery Chemistry Lithium-Ion
Fault Protection Over Voltage
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 4
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 20V
Function Battery Protection
Base Part Number BQ296112
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 14.4V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~110°C TA

Physical

Number of Pins 8
Surface Mount YES
Package / Case 8-WFDFN Exposed Pad
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
