BQ27Z561YPHT
RoHS
RoHS compliant
RoHS compliantPackage 12-XFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
BOTTOM Tape & Reel (TR) BQ27Z561 Impedance Track? battery management 5.5V 2.05mm -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.97
Unit Price: USD $1.9712
≥1 USD $1.9712
≥10 USD $1.76968
≥100 USD $1.673056
≥500 USD $1.449888
Inventory: 747
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 12-XFBGA, DSBGA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series Impedance Track?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
Terminal Position BOTTOM
Terminal Form BALL
Terminal Pitch 0.5mm
Base Part Number BQ27Z561
Function Fuel Gauge
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2V
Number of Channels 1
Interface HDQ, I2C
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold NO
Battery Chemistry Lithium Ion/Polymer
Number of Cells 1
Dimensions
Height Seated (Max) 0.4mm
Length 2.05mm
Compliance
RoHS Status ROHS3 Compliant
