BQ26200PWG4
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free Gold ROHS3Compliant Battery Monitor IC Battery Monitor -20C~70C TA 4.4mm 5.5V 5mA
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.359453
≥1 USD $5.359453
≥10 USD $5.056091
≥100 USD $4.769889
≥500 USD $4.499899
≥1000 USD $4.245187
Inventory: 1180
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 3mm
Height 1.2mm
Technical
Number of Cells 1 ~ 4
Battery Chemistry Multi-Chemistry
Adjustable Threshold NO
Output Current 5mA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 2.8V
Max Supply Voltage 5.5V
Interface HDQ
Number of Channels 1
Function Battery Monitor
Base Part Number BQ26200
Terminal Pitch 0.65mm
Supply Voltage 3.6V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -20°C~70°C TA
Physical
Weight 33.594185mg
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
