BQ24351DSGT
RoHS
RoHS compliant
RoHS compliantPackage 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
ACTIVE (Last Updated: 3days ago) DUAL Tape & Reel (TR) e4 battery management 1mA 15V 2mm -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.3
Unit Price: USD $1.3024
≥1 USD $1.3024
≥10 USD $1.16424
≥100 USD $1.104928
≥500 USD $0.907632
Inventory: 830
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 750μm
Width 2mm
Length 2mm
Height 800μm
Technical
Battery Chemistry Lithium-Ion
Fault Protection Over Current, Over Temperature, Over/Under Voltage, Short Circuit
Threshold Voltage +1.95V
Supply Current-Max (Isup) 0.5mA
Adjustable Threshold NO
Output Current 1mA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 4.4V
Max Supply Voltage 15V
Number of Channels 1
Power Supplies 5V
Output Voltage 6.38V
Function Battery Protection
Base Part Number BQ24351
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Subcategory Power Management Circuits
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-WFDFN Exposed Pad
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
