BQ2083DBTR
RoHS
RoHS compliant
RoHS compliantPackage 38-TFSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free ROHS3Compliant Battery Monitor GULL WING IC Battery Monitor -20C~85C TA 4.4mm 3.6V
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1097
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 38-TFSOP (0.173, 4.40mm Width)
Number of Pins 38
Weight 124.000814mg
Technical
Operating Temperature -20°C~85°C TA
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 38
ECCN Code EAR99
HTS Code 8542.39.00.01
Subcategory Power Management Circuits
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number BQ2083
Function Battery Monitor
Qualification Status Not Qualified
Output Voltage 400mV
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Channels 1
Interface SMBus
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold YES
Battery Chemistry Lithium Ion/Polymer
Dimensions
Height Seated (Max) 1.2mm
Length 9.7mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
