DS2770BE+
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
ROHS3Compliant Multi-Function Controller GULL WING Obsolete IC Multi-Function Controller -20C~70C TA 4.4mm 5.5V
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.154748
≥1 USD $0.154748
≥10 USD $0.145989
≥100 USD $0.137724
≥500 USD $0.129928
≥1000 USD $0.122569
Inventory: 1264
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -20°C~70°C TA
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish MATTE TIN
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 4.1V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDSO-G16
Function Multi-Function Controller
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Interface 1-Wire
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold NO
Battery Chemistry Multi-Chemistry
Dimensions
Height Seated (Max) 1.1mm
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
