MAX6431EIUS+T
RoHS
RoHS compliant
RoHS compliantPackage TO-253-4, TO-253AA
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free ROHS3Compliant Battery Monitor GULL WING IC Battery Monitor 320mW -40C~85C TA 1.3mm 5.5V
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.8216
≥1 USD $1.8216
Inventory: 1110
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.3mm
Technical
Number of Cells 2
Battery Chemistry Multi-Chemistry
Max Reset Threshold Voltage 5.5V
Min Reset Threshold Voltage 1.2V
Supply Current-Max (Isup) 0.0015mA
Watchdog Timer No
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1.6V
Number of Channels 2
Operating Supply Voltage 5.5V
Function Battery Monitor
Base Part Number MAX6431
Supply Voltage 3.7V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 320mW
Subcategory Power Management Circuits
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 4
Package / Case TO-253-4, TO-253AA
Mounting Type Surface Mount
Mount Surface Mount
