MAX6429NSUR+T
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free ROHS3Compliant Battery Monitor GULL WING IC Battery Monitor 320mW -40C~85C 2.92mm 5.5V
PDF
/
Inventory: 2033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 2.92mm
Height Seated (Max) 1.12mm
Technical
Battery Chemistry Multi-Chemistry
Max Reset Threshold Voltage 5.5V
Min Reset Threshold Voltage 1.2V
Supply Current-Max (Isup) 0.0015mA
Watchdog Timer No
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1.6V
Number of Channels 1
Power Supplies 1.2/5V
Operating Supply Voltage 5.5V
Function Battery Monitor
Base Part Number MAX6429
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.95mm
Supply Voltage 3.7V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 320mW
Subcategory Power Management Circuits
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 111 Weeks
