MAX6428DHUR+
RoHS
RoHS compliant
RoHS compliantPackage SOT-23
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
ROHS3Compliant INDUSTRIAL GULL WING Obsolete IC (Function) 320mW 85C 2.92mm 5.5V
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
Inventory: 1168
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOT-23
Number of Pins 3
Technical
Packaging Bulk
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Power Management Circuits
Max Power Dissipation 320mW
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.7V
Terminal Pitch 0.95mm
Pin Count 3
Power Supplies 1.2/5V
Temperature Grade INDUSTRIAL
Number of Channels 1
Max Supply Voltage 5.5V
Min Supply Voltage 1.6V
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold NO
Watchdog Timer No
Supply Current-Max (Isup) 0.0015mA
Min Reset Threshold Voltage 1.2V
Max Reset Threshold Voltage 5.5V
Dimensions
Height Seated (Max) 1.12mm
Length 2.92mm
Compliance
RoHS Status ROHS3 Compliant
