DS1259S+ image
Favorite
DS1259S+ image
Favorite
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description Lead Free ROHS3Compliant Power Management GULL WING IC Power Management 0C~70C TA 7.5mm 5.5V
PDF
/
Buying Options
Total Price: USD $10.59
Unit Price: USD $10.585733
≥1 USD $10.585733
≥10 USD $9.98654
≥100 USD $9.421269
≥500 USD $8.887985
≥1000 USD $8.384893
Inventory: 9057
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES

Technical

Operating Temperature 0°C~70°C TA
Packaging Tube
Published 1999
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS1259
JESD-30 Code R-PDSO-G16
Function Power Management
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Number of Channels 1
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold NO

Dimensions

Height Seated (Max) 2.65mm
Length 10.3mm
Width 7.5mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
