LTC4098EPDC#PBF
RoHS
RoHS compliant
RoHS compliantPackage 20-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
QUAD Tube R-PQCC-N20 Matte Tin (Sn) battery management 5.5V 2650kHz 3mm -40C~85C TA
PDF
/
Buying Options
Total Price: USD $257.34
Unit Price: USD $257.3398
≥1 USD $257.3398
≥10 USD $230.7189
Inventory: 607
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Number of Cells 1
Battery Chemistry Lithium Ion/Polymer
Fault Protection Over Voltage
Switching Frequency-Max 2650kHz
Switcher Configuration BUCK-BOOST
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 5.5V
Control Mode CURRENT-MODE
Input Voltage (Min) 4.35V
Analog IC - Other Type BATTERY CHARGE CONTROLLER
Interface USB
Input Voltage-Nom 5V
Qualification Status Not Qualified
Function Multi-Function Controller
JESD-30 Code R-PQCC-N20
Base Part Number LTC4098
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code compliant
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 250
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PowerPath?
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 20-UFQFN Exposed Pad
Mounting Type Surface Mount
