LTC4066EUF-1#TRPBF image
Favorite
LTC4066EUF-1#TRPBF image
Favorite
RoHS
RoHS RoHS compliant
Package 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description ROHS3Compliant Multi-Function Controller VOLTAGE-MODE NO LEAD IC Multi-Function Controller -40C~85C TA 4mm 5.5V 0.525A
PDF
/
Buying Options
Total Price: USD $3.72
Unit Price: USD $3.71735
≥1 USD $3.71735
≥10 USD $3.05045
≥100 USD $2.95545
≥500 USD $2.8595
≥1000 USD $2.7645
Inventory: 1119
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mounting Type Surface Mount
Package / Case 24-WFQFN Exposed Pad
Surface Mount YES

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LTC4066
JESD-30 Code S-PQCC-N24
Function Multi-Function Controller
Qualification Status Not Qualified
Input Voltage-Nom 5V
Interface USB
Analog IC - Other Type BATTERY CHARGE CONTROLLER
Input Voltage (Min) 4.35V
Control Mode VOLTAGE-MODE
Output Current-Max 0.525A
Input Voltage (Max) 5.5V
Switcher Configuration SINGLE
Fault Protection Over Current
Battery Chemistry Lithium-Ion
Number of Cells 1

Dimensions

Height Seated (Max) 0.8mm
Length 4mm
Width 4mm

Compliance

RoHS Status ROHS3 Compliant
