VIPER15LN
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm), 7 Leads
Category Integrated Circuits (ICs) / PMIC - AC DC Converters, Offline Switchers
Description
VIPER15 Current Limiting Over Temperature Over Voltage Tube VIPer? plus dc ac converter 23.5V 9.27mm 12W 136kHz
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $1.10088
≥100 USD $1.045088
≥500 USD $0.858616
≥1000 USD $0.802595
≥3000 USD $0.709262
Inventory: 1140
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm), 7 Leads
Number of Pins 7
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Series VIPer? plus
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Power (Watts) 10W
Subcategory Switching Regulator or Controllers
Max Power Dissipation 12W
Terminal Position DUAL
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number VIPER15
Pin Count 7
Number of Outputs 1
Input Voltage-Nom 14V
Analog IC - Other Type SWITCHING CONTROLLER
Operating Supply Current 900μA
Nominal Supply Current 2.5mA
Voltage - Supply (Vcc/Vdd) 8.5V~23.5V
Output Power 12W
Input Voltage (Min) 8.5V
Topology Flyback
Control Mode CURRENT-MODE
Frequency - Switching 136kHz
Input Voltage (Max) 23.5V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration SINGLE
Internal Switch(s) Yes
Fault Protection Current Limiting, Over Temperature, Over Voltage
Output Isolation Isolated
Voltage - Breakdown 800V
Voltage - Start Up 14V
Dimensions
Height 3.3mm
Length 9.27mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
