2149152-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
TE CONNECTIVITY 2149152-1 I/O Connector, I/O, Receptacle, 84 Contacts, Press Fit, PCB Mount
PDF
/
Buying Options
Total Price: USD $49.17
Unit Price: USD $49.1744
≥1 USD $49.1744
≥10 USD $40.58912
≥100 USD $37.72736
≥500 USD $35.645773
≥1000 USD $34.865257
Inventory: 180
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polymer
Technical
Packaging Tray
Published 2011
Feature Board Guide, EMI Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type CXP
Number of Positions 84
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Gender Receptacle
Voltage - Rated 120V
HTS Code 8536.69.40.30
Pitch 11.88mm
Orientation Right Angle
Depth 53.4mm
Current Rating 500mA
Contact Finish Gold
Housing Color Black
ELV Compliant
Max Current Rating 500mA
Plating Nickel, Tin
Connector Style Receptacle with Cage
Number of Ports 1
Sealable Yes
Circuit Application Signal
Data Rate 125 Gbps
Dimensions
PCB Thickness 1.5748mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
